155€
Product Code: 14316
RF Frequency Band |
2400 to 2483.5 MHz
|
RF Bandwidth |
Up to 83.5 MHz
|
RF Channel Scanning |
Auto-Scan
|
Max Operating Range |
328' / 100 m (Line of Sight)
|
Built-In Recorder |
No
|
Timecode Support |
No
|
Bluetooth |
Yes
|
Sample Rate/Resolution |
44.1 kHz / 24-Bit
|
Latency |
12 ms
|
Encryption |
None
|
Modulation |
GFSK
|
Transmitter Type |
Clip-On with Microphone
|
RF Output Power |
10 mW
|
Audio I/O |
1 x 1/8" / 3.5 mm TRS Female Unbalanced Input
|
Included Cable Connector |
None
|
Pad |
None
|
Muting |
Mute Switch
|
Audio Input Level |
-42 to -30 dBV (at 0 dB Gain)
|
Auto-Level Control |
No
|
Signal Processing |
None
|
Sync Method |
IR
|
Antenna |
1 x 1/4 Wave Internal
|
Power Requirements |
Battery or Bus Power (USB)
|
Battery Type |
1 x Built-In Rechargeable (Included, Not Replaceable)
|
Battery Charging Time |
3 Hours
|
Approx. Battery Life |
8 Hours
|
USB/Lightning I/O |
1 x Micro-USB (Bus Power, Charging)
|
Display & Indicators |
1 x OLED (Audio Level, Battery Status, Mute, Power, Signal Strength)
|
Operating Temperature |
32 to 122°F / 0 to 50°C
|
Storage Temperature |
-4 to 131°F / -20 to 55°C
|
Dimensions |
2.2 x 1.5 x 1" / 5.7 x 3.8 x 2.6 cm
|
Weight |
1.1 oz / 32 g
|
Microphone Type |
Lavalier
|
Color |
Black
|
Sound Field |
Mono
|
Operating Principle |
Pressure Operated
|
Capsule |
Electret Condenser
|
Polar Pattern |
Omnidirectional
|
Maximum SPL |
110 dB SPL
|
THD |
< 1%
|
Impedance |
2.2 Kilohms
|
Sensitivity |
-39 dB
|
Output Connector |
1 x 1/8" / 3.5 mm TRS Male Unbalanced
|
Cable Length |
4.1' / 1.2 m
|
Operating Voltage |
1 to 10 V
|
Operating Current Consumption |
500 µA
|
Second Microphone Type |
Integrated
|
Sound Field |
Mono
|
Operating Principle |
Pressure Operated
|
Capsule |
Electret Condenser
|
Polar Pattern |
Omnidirectional
|
Frequency Range |
50 Hz to 18 kHz
|
SNR |
78 dB
|
Maximum SPL |
120 dB SPL
|
Sensitivity |
-39 dB
|
Wireless Technology |
Digital 2.4 GHz
|
Max Operating Range |
328' / 100 m (Line of Sight)
|
Transmitter Type |
Clip-On with Microphone
|
Audio I/O |
1 x 1/8" / 3.5 mm TRS Female Unbalanced Input
|
Microphone Type |
Lavalier
|
Polar Pattern |
Omnidirectional
|
Second Microphone Type |
Integrated
|
Polar Pattern |
Omnidirectional
|
